110
INTELLIGENT ACTUATOR
Chapter 4 Commands
2.
Explanation
of
Commands
1-8 Program Control
z GOTO (Jump)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Optional Optional GOTO Tag number Prohibited CP
[Function] Jump to the position of the tag number specified in operand 1.
(Note) A GOTO command is valid only within the same program.
[Example 1] TAG 1 Set a tag.
:
:
:
GOTO 1 Jump to tag 1.
Using a GOTO command to branch out of or into any of the syntaxes listed below is prohibited.
Since the maximum number of nests is defined for each conditional branching command or subroutine call, a
nest will be infinitely repeated if an EDXX is not passed, and a nest overflow error will generate. In the case of
palletizing setting, an error will generate if the second BGPA is declared after the first BGPA declaration without
passing an EDPA.
(1) IFXX or ISXX and EDIF syntax
(2) DWXX and EDDO syntax
(3) SLCT and EDSL syntax
(4) BGSR and EDSR syntax
(5) BGPA and EDPA syntax
z TAG (Declare tag)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Prohibited Prohibited TAG Tag number Prohibited CP
[Function] Set the tag number specified in operand 1.
[Example 1] Refer to the section on GOTO command.
