Chapter 3
Offset Tables and Setup
3-27
5. Data can be replaced or added to:
(softkey level 4)
REPLCE
VALUE
ADD TO
VALUE
MORE
LIMITS
UPDATE
& EXIT
QUIT
If you want to: Key in the: Press this softkey:
replace stored zone data with new data new data {REPLCE VALUE}
add to previously stored zone data amount to be added {ADD TO VALUE}
6. When you have finished editing the inhibit zone data:
(softkey level 4)
REPLCE
VALUE
ADD TO
VALUE
MORE
LIMITS
UPDATE
& EXIT
QUIT
If you want to: Press this softkey:
save all changes you just made {UPDATE & EXIT}
delete all changes you just made {QUIT}
Unlike the other tables described in this chapter, the zone table cannot be
backed up with a G10 program.
Use this feature to change the values set for the single-digit feedrates.
When a single-digit F word is encountered during block execution, the
control looks to the single-digit feedrate table for a feedrate. The feedrate
in this table corresponding to the single-digit F word then becomes the
active feedrate. For details on single-digit F words, see page 12-61.
To display or alter the values in the single-digit feedrate table, follow these
steps:
1. Press the {SYSTEM SUPORT} softkey.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
3.10
Single-Digit Feedrate Table
