Rockwell Automation 8520-GUM 9/Series CNC Grinder Operation and Programming Manual Documentation Set User Manual
Page 124

Editing Programs On Line
Chapter 5
5-4
ATTENTION: Any edit operation on a part program is
permanent. You cannot discard any changes that you made to a
program. The control saves programs in memory at the same
time they are edited.
Two major areas of the edit screen are dedicated to displaying specific
information:
Line
Area
Content
2 - 3
input lines
when the data is entered, the control displays the character here.
7 - 20
program display
lines
the control displays the part program blocks as they are currently
been edited.
INSERT :
EDIT
FILE : 000001
POS
1*1 MODE : CHAR
N00020
WHILE [#1LT 10] DO 1;
N00025
G01 F1000
X#1;
N00030
G04 P1
N00035
#1 = [#1 + 1];
N00040
END 1;
N00050
M99;
MODIFY
INSERT
BLOCK
DELETE
BLOCK
TRUNC
DELETE
CH/WRD
EXIT
EDITOR
line 2-3
Input
lines
area
line 7-20
Program
lines area
The following subsections describe in detail, the use of the features
available when editing a part program.
