Chapter 3
Offset Tables and Setup
3-25
5. When you press the {TO FILE} softkey, the control prompts you for
a program name. Enter a program name by using the alphanumeric
keys on the operator panel and press the [TRANSMIT] key (see page
10-8 on program names).
If you press {TO PORT A} or {TO PORT B} instead of {TO FILE}
the control sends the backup program to the device connected to the
peripheral port.
The programmable zone table feature provides a means to prevent wheel
motion from entering or exiting a designated area. For details on
programmable zones, see page 11-34.
This table contains the values for programmable zones 2 and 3. These
values define the boundaries for the programmable zones and are
referenced from the machine coordinate system.
Important: These values can also be entered in AMP by your system
installer. You can also modify programmable zone 3 table values by
programming a G22 command. See page 11-40 for details.
To display or alter the values in the programmable zone table, follow these
steps:
1. Press the {SYSTEM SUPORT} softkey.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
2. Press the {PRGRAM PARAM} softkey.
(softkey level 2)
PRGRAM
PARAM
AMP DEVICE
SETUP
MONI-
TOR
TIME
PARTS
PTOM
SI/OEM
SYSTEM
TIMING
3.9
Programmable Zone Table
