1 moving the cursor – Rockwell Automation 8520-GUM 9/Series CNC Grinder Operation and Programming Manual Documentation Set User Manual
Page 125

Editing Programs On Line
Chapter 5
5-5
This section covers moving the cursor in the program display area (lines
7-20 of the CRT). It assumes that you have selected a program to edit as
covered on page 5-1.
The input cursor is the cursor shown on the input lines (lines 2 and 3 on the
screen). Details on the input cursor are given on page 2-41.
To move the block cursor:
Press these cursor keys on the operator panel:
right and left
right and left
up and down
up and down
up or down one full screen display
up or down cursor keys while holding down the [SHIFT]
key
To search for a character or character string, press the continue {
→
}
softkey to change the softkey functions and follow these steps:
1.
Press the
{STRING SEARCH}
softkey.
DIGITZ
E
MODIFY
INSERT
BLOCK
DELETE
BLOCK
TRUNC
DELETE
CH/WRD
EXIT
EDITOR
STRING
SEARCH
RENUM
PRGRAM
MERGE
PRGRAM
QUICK
VIEW
CHAR/
WORD
(softkey level 3)
2.
Move the cursor to the beginning or end of the part program:
(softkey level 4)
FORWRD REVRSE
TOP OF
PRGRAM
BOT OF
PRGRAM
To move the cursor to the:
Press this softkey:
beginning of the part program
{TOP OF PROG}
end of the part program
{BOT OF PROG}
3.
Key in the character or character string to search for.
5.2.1
Moving the Cursor
{STRING SEARCH}
