Rockwell Automation 8520-GUM 9/Series CNC Grinder Operation and Programming Manual Documentation Set User Manual
Page 298

Introduction to Programming
Chapter 10
10-20
Address
Function
Valid Range
metric
Valid Range
inch
S
5.3
3.3
4.3
5.3
3.3
3.3
Spindle rpm function
Spindle Orient
CSS
T
6.0
6.0
Tool selection function
U
5.3
5.3
Length of dwell in G04 and fixed cycles.
X
8.6
5.3
8.5
5.3
Main axis (AMP assigned)
Length of dwell in G04
Y
8.6
8.5
Main axis (AMP assigned)
Z
8.6
8.5
Main axis (AMP assigned)
The maximum programmable value accepted by the control is 99,999,999.
The minimum is .000001 inch or .00001mm. However, the actual range of
programmable values depends on specifications determined by your
system installer.
By using AMP to establish the format of numeric values for words, your
system installer sets the “programming resolution,” for axis motion, that is,
the smallest programmable distance of axis motion.
Table 10.C
Programming Resolutions
Formats as set in
AMP
_.3
_.4
_.5
_.6
Corresponding
Resolution
0.001
0.0001
0.00001
0.000001
See your system installer’s documentation for the programming resolutions
and ranges in a specific system.
10.4.1
Minimum and Maximum
Axis Motion
(Programming Resolution)
