Rockwell Automation 8520-GUM 9/Series CNC Grinder Operation and Programming Manual Documentation Set User Manual
Page 191
Running a Program
Chapter 7
7-3
To enter a sequence number to stop execution:
1.
Press the
{PRGRAM MANAGE}
softkey. A program must have already
been selected for automatic execution as described on page 7-6.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
2.
Press the
{ACTIVE PRGRAM}
softkey.
REFORM
MEMORY
CHANGE
DIR
ACTIVE
PRGRAM
EDIT
PRGRAM
RESTRT
PRGRAM
DISPLY
PRGRAM
COPY
PRGRAM
VERFY
PRGRAM
PRGRAM
COMENT
DELETE
PRGRAM
RENAME
PRGRAM
INPUT
DEVICE
(softkey level 2)
3.
Press the
{SEQ STOP}
softkey.
(softkey level 3)
DE-ACT
PRGRAM
SEARCH MID ST
PRGRAM
T PATH
GRAPH
SEQ
STOP
TIME
PARTS
4.
Key in the sequence number where automatic operation in the part
program is to stop, then press the
[TRANSMIT]
key.
The control stops automatic operation after it completes the
commands in that block.
Press the
button to continue execution of the
program from the point at which program execution was stopped.
