Chapter 3
Offset Tables and Setup
3-24
The backup offset screen appears:
TO
PORT A
TO
PORT B
TO
FILE
BACKUP TOOL OFFSETS
RADIUS TABLE
WHEEL GEOMETRY TABLE
WORK COORDINATE OFFSETS
ALL
SELECT OPTION USING THE UP/DOWN ARROW
3. Select the offsets you want to back up by using the up and down
cursor keys. The selected offset appears in reverse video. Select one
of four options:
If you want your G10 program to contain: Select:
all data from the radius offset table RADIUS TABLE
all data from the wheel geometry tables WHEEL GEOMETRY
the work coordinate offset information for G54 -
G59.3 and the external offset value WORK COORDINATE
all data from the wheel geometry, radius offset,
and work coordinate offset tables ALL
4. Once you have indicated the data you want to save, determine the
destination for the G10 program from these 3 options:
If you want to send the G10
program to:
Press this softkey:
a peripheral attached to port A {TO PORT A}
a peripheral attached to port B {TO PORT B}
control memory {TO FILE}
