Chapter 2
Operating the Control
2-44
The time parts count display logs data relevant to part program execution,
including:
number of parts ground
cycle time
lot size
remaining parts
You display and alter this data through the time parts screen.
Three levels of access are available to the time parts screen. They are
listed below in order of most restrictive to least restrictive. See page 2-27
for details on password protection and access control.
Degree of
Restriction: Access Level: Type of Restriction:
Most restrictive No access Restricts operator from Time Parts screen entirely
(softkey {TIME PARTS} not accessible).
Accomplished by denying access to “Active Program.”
Moderately
restrictive Operator access Restricts operator from setting “Date” or “Time”
(softkeys {SET TIME} and {SET DATE} do not
appear). Also restricts operator from setting “Power-on
time/overall” and “Workpieces cut/overall.”
Accomplished by denying access to “Time Parts.”
Least restrictive Supervisor access Full access to all features of the Time Parts screen.
To access the time parts screen, follow these steps:
1. Press the {PRGRAM MANAGE} softkey.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
2.14
Time Parts Count
Display Feature
