Page 123

Editing Programs On Line

Chapter 5

5-3

Select the part program you want to edit by using one of these two
methods:

Key in the program name of the part program to edit or create

Move the cursor to the program name on the program directory
screen by using the up and down cursor keys

Important: If you are creating a new program and using it as a
subprogram, see page 10-8 on program names. Programs used as
subprograms must have the letter O as the first character in the
program name, followed by up to 5 numeric characters.

Press the

{EDIT PRGRAM}

softkey.

REFORM

MEMORY

CHANGE

DIR

ACTIVE

PRGRAM

EDIT

PRGRAM

RESTRT

PRGRAM

DISPLY

PRGRAM

COPY

PRGRAM

VERIFY

PRGRAM

COMENT

DELETE

PRGRAM

RENAME

PRGRAM

INPUT

DEVICE

(softkey level 2)

This section provides information on how to edit part programs after a
program has already been selected to edit as described on page 5-1.

This section contains the following subsections:

Topic:

On Page:

Moving the Cursor {STRING SEARCH}

5-5

Entering Characters and Blocks

5-7

Changing and Inserting {MODIFY INSERT}

5-7

Erasing Characters and Blocks

5-10

Sequence Numbers {RENUM PRGRAM}

5-13

Merging Part Programs {MERGE PRGRAM}

5-15

Exiting Edit Mode

5-15

5.2
Editing Programs at the
Control (on line)
