Chapter 3
Offset Tables and Setup
3-17
This feature allows the manual activation of wheel length and
radius/orientation offsets without the need to program the correct T word
to call the corresponding offset number.
Typically you change the wheel length and radius/orientation offsets by
programming a T word as described in chapter 13. Use this feature only
when you need to activate one of these offset numbers manually.
Important: The control must be in cycle stop or E-STOP state before an
attempt is made to change the active offset using this method.
1. Press the {OFFSET} softkey.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
2. Press the {WHEEL GEOMET} softkey to activate a wheel length
offset number, or press the {RADIUS TABLE} softkey to activate a
radius/orientation offset number.
(softkey level 2)
WORK
CO-ORD
WHEEL
GEOMET
RADIUS
TABLE
DRESSR
TABLE
SCALNG
COORD
ROTATE
BACKUP
OFFSET
The control displays the offset table. Currently active offset values
(if any) are indicated with a * to the right of the offset number if you
have selected the radius table. If you selected the wheel geometry
table, the * is to the left of the offset number.
3. Move the cursor (using cursor keys) on the offset table until the
desired offset appears in reverse video. Only one length and one
radius/orientation offset number can be active at any time.
3.6
Changing the Active
Dresser/Wheel Offset
{ACTIVE OFFSET}
