Editing Programs On Line
Chapter 5
5-14
3.
Key in an initial sequence number (the number for the first sequence
number), a comma, and an incremental value for the control to add to
each new sequence number. The format to this command is
RENUM: initial-sequence-number, incremental-value
For example
RENUM:5,10
would make the first sequence number 5, the next 15, 25, 35....
Important: You must enter both the initial sequence number and the
incremental value as integer values. If you use a decimal point, the control
issues the error message “ILLEGAL VALUE”.
If no initial sequence number or no incremental value is given or
both are not entered, the control uses default values of one.
4.
Select the blocks to renumber by using one of the two choices:
(softkey level 4)
ALL
ONLY
N
If you want to:
Then press:
assign sequence numbers or to reassign sequence numbers to
all blocks from the beginning of the part program
{ALL} softkey
assign new sequence numbers to only the blocks that already
have sequence numbers
{ONLY N}
softkey
ATTENTION: When the control performs a renumber
operation, features in the part program that reference a specific
block number may no longer be referencing the correct block.
For example, a paramacro GOTO 10 command may not call the
correct block after the renumber operation. When a renumber
operations is performed, you must manually go through the
program to make sure that these block references are correct.
