Cylindrical grinding fixed cycles, 0 chapter overview – Rockwell Automation 8520-GUM 9/Series CNC Grinder Operation and Programming Manual Documentation Set User Manual
Page 575

Chapter
17
17-1
Cylindrical Grinding Fixed Cycles
This chapter describes the cylindrical grinding cycles available with the
control. You can use these cycles to program axis motions to perform
common grinding operations. Topics include:
Topic:
On page:
Cylindrical Grinding Considerations
17-3
Cylindrical Grinding Parameters
17-9
G81 and G81.1 Reciprocation without Plunge
17-11
G82 and G82.1 Incremental Face Grinding (axis 1)
17-12
G83 and G83.1 Incremental Plunge Grinding (axis 2)
17-16
G84 and G84.1 Multi-pass Face Grinding (axis 1)
17-20
G85 and G85.1 Multi-pass Diameter Grinding (axis 2)
17-23
G86 and G86.1 Shoulder Grinding
17-26
G87 and G87.1 Shoulder Grinding with Face Plunge
17-28
G88 and G88.1 Shoulder Grinding with Diameter Plunge
17-30
G89 and G89.1 Multi-Step Plunge Grinding with Blend
17-32
Cycle not available on 9/240 grinder systems
Figure 17.1 shows the motions of the eight cylindrical grinding cycles
described in this chapter.
17.0
Chapter Overview
