Manual/MDI Operation Modes

Chapter 4

4-3

During a jog retract operation (see chapter 7), you are permitted to use
only normal single axis jogs (one axis at a time in the continuous,
incremental, or HPG modes).

To jog an axis continuously:

1.

Select CONTINUOUS under

.

2.

Select the feedrate for continuous jog under

.

If you want to:

Then:

alter the feedrate selected with the
switch

select a %

jog the axis at a special AMP assigned
traverse feedrate and ignore the setting of
the switch

press and hold the when jogging

jog moves that use the traverse feedrate

select a OVERRIDE> %

For details on using the feedrate override switches, see chapter 11.

3.

Press the

button for the axis and direction to jog.

The axis moves while the button is held down.

Important: You can jog more than one axis at a time. To jog
multiple axes, press and hold more than one axis direction button.
The selected axes drive at the feedrate chosen with the

switch. If the selected feedrate is above a

specific axis maximum allowable feedrate, that axis drives at its
maximum feedrate. The feedrate for the other selected axes is not
affected.

Incremental jog manually moves an axis a predetermined amount each
time you press the

button. To use incremental jog:

1.

Select INCREMENTAL under

.

2.

Select the jog increment under

. The jog

increment is equal to an amount specified in AMP for each selection
under

.

3.

Press the

button for the axis and direction to jog.

The control makes one incremental move each time it recognizes the

button. Until the control completes the execution

of the incremental move, no other jog moves are recognized on that

4.1.2
Continuous Jog

4.1.3
Incremental Jog
