Running a program – Rockwell Automation 8520-GUM 9/Series CNC Grinder Operation and Programming Manual Documentation Set User Manual
Page 189

Chapter
7
7-1
Running a Program
This chapter describes how to test a part program and execute it in
automatic mode. Major topics covered here include:
Topic:
On page:
Selecting Special Running Conditions
7-1
Block Delete
7-2
Miscellaneous Function Lock
7-2
Sequence Stop {SEQ STOP}
7-2
Single Block
7-4
Selecting a Part Program Input Device
7-5
Selecting a Program
7-6
De-Selecting a Part Program
7-9
Program Search {SEARCH}
7-10
Search With Recall {MID ST PRGRAM}
7-13
Basic Program Execution
7-16
{QUICK CHECK}
7-18
Axis Inhibit Mode
7-20
Dry Run Mode
7-21
Part Production/Automatic Mode
7-22
Interrupted Program Recover {RESTRT PRGRAM}
7-24
Jog Retract
7-27
Block Retrace
7-30
The following subsections describe some of the available functions on the
control that affect how the control executes a program. The use of these
“special running conditions” is optional. They are activated either through
the MTB panel, through programming, through the
{FRONT PANEL}
softkey, or some combination of the three.
7.0
Chapter Overview
7.1
Selecting Special Running
Conditions
