Introduction to Programming
Chapter 10
10-27
Surface
Grinder
Modal or
Non-modal
Function
Group
Number
Cylindrical
Grinder
G59.3
G59.3
12
Preset Work Coordinate System 9
Modal
G61
G61
13
Exact stop mode
G62
G62
Automatic corner override mode
G64
G64
Cutting mode
G65
G65
00
Paramacro Call
Non-modal
G66
G66
14
Modal paramacro call
Modal
G66.1
G66.1
Modal paramacro call
G67
G67
Modal paramacro call cancel
G68
G68
16
Part rotation
G69
G69
Part rotation cancel
G70
G70
06
Inch input
G71
G71
Metric input
G80
G80
09
Canned cancel
G81
G81
Reciprocation on
G81.1
G81.1
Reciprocation with predress on
G82
-- --
Plunge grind cycle, axis 1
-- --
G82
Incremental face grind cycle, axis 1
G82.1
Plunge grind with predress, axis 1
-- --
G82.1
Incremental face grind with predress, axis 1
G83
-- --
Incremental plane grind, axis 1 plunge
-- --
G83
Incremental plunge grind, axis 2 plunge
G83.1
-- --
Incremental plane grind, axis 1 plunge with predress
-- --
G83.1
Incremental plunge grind, axis 2 plunge with predress
G84
-- --
Incremental plane grind, axis 2 plunge
-- --
G84
Multi-pass face cycle
G84.1
Incremental plane grind, axis 2 plunge with predress
-- --
G84.1
Multi-pass face cycle with predress
G85
-- --
Continuous plane grind, axis 1 plunge
-- --
G85
Multi-pass diameter plunge
G85.1
-- --
Continuous plane grind, axis 1 plunge with predress
-- --
G85.1
Multi-pass diameter plunge with predress
G86
-- --
Continuous plane grind, axis 2 plunge
-- --
G86
Shoulder grind cycle
G86.1
Continuous plane grind, axis 2 plunge with predress
-- --
G86.1
Shoulder grinder cycle with predress
-- --
G87
Face plunge shoulder cycle
-- --
G87.1
Face plunge shoulder cycle with predress
-- --
G88
Diameter plunge shoulder cycle
Modal
