Configuration Registers
3-13
Register: 0x00
Vendor ID
Read Only
VID
Vendor ID
[15:0]
This 16-bit register identifies the manufacturer of the
device. The Vendor ID is 0x1000.
Register: 0x02
Device ID
Read Only
DID
Device ID
[15:0]
This 16-bit register identifies the particular device. The
LSI53C875 Device ID is 0x000F.
Register: 0x04
Command
Read/Write
The
register provides coarse control over a device’s ability to
generate and respond to PCI cycles. When a zero is written to this
register, the LSI53C875 is logically disconnected from the PCI bus for all
accesses except configuration accesses.
In the LSI53C875, bits 3, 5, 7, and 9 are not implemented. Bits 10
through 15 are reserved.
