5-29
Register: 0x0F (0x8F)
SCSI Status Two (SSTAT2)
Read Only
ILF1 SIDL Most Significant Byte Full 7
This bit is set when the most significant byte in the SCSI
Input Data Latch (SIDL) contains data. Data is transferred
from the SCSI bus to the SCSI Input Data Latch register
before being sent to the DMA FIFO and then to the host
bus. The
SCSI Input Data Latch (SIDL) register contains
SCSI data received asynchronously. Synchronous data
received does not flow through this register.
ORF1 SODR Most Significant Byte Full 6
This bit is set when the most significant byte in the SCSI
Output Data Register (SODR, a hidden buffer register
which is not accessible) contains data. The SODR
register is used by the SCSI logic as a second storage
register when sending data synchronously. It is not
accessible to the user. This bit is used to determine how
many bytes reside in the chip when an error occurs.
OLF1 SODL Most Significant Byte Full 5
This bit is set when the most significant byte in the SCSI
Output Data Latch (SODL) contains data. The SCSI Out-
put Data Latch (SODL) register is the interface between
the DMA logic and the SCSI bus. In synchronous mode,
data is transferred from the host bus to the
SCSI Output
Data Latch (SODL) register, and then to the SCSI Output
Data Register (SODR, a hidden buffer register which is
not accessible) before being sent to the SCSI bus. In
asynchronous mode, data is transferred from the host
bus to the
SCSI Output Data Latch (SODL) register, and
then to the SCSI bus. The SODR buffer register is not
used for asynchronous transfers. It is possible to use this
bit to determine how many bytes reside in the chip when
an error occurs.
7 6 5 4 3 2 1 0
ILF1 ORF1 OLF1 FF4 SPL1 R LDSC SDP1
0 0 0 0 x x 1 x
