20.12 System Variables in the Visualization
The following implicitely created system variables can be used to program a
visualization:
Currently usable in Implicitely
generated
variable
Data type Function
HMI Simu
lation
Target
Visu Web
Visu
CurrentVisu String[40] Name of the currently opened visualization. If the
name gets changed, a change to another visualization
will be done.
Note : With compiler versions
< V2.3.7.0 the name string MUST be defined in capital
letters. With compiler versions as from V2.3.7.0 the
string can be defined in small letters IF the library
SysLibStr.lib is included in the project.
Depending on the target system this variable can be
activated/deactivated in the Target Settings dialog,
category Visualization.
x x x x
CurrentCalle
r String[40] Name of the previously opened visualization. Is used
for the ZOOMTOCALLER functionality. Only set and
modified in TargetVisu.
- - x -
CurrentLang
uage String[40] Currently set language, available in the language file.
The language. Only set and modified in TargetVisu.
- - x -
CurrentUser
Level * INT Currently set user level 0..7. x x x x
CurrentPass
words
[0 .. 7] * ARRAY
[0..7]
of
String[20]
All passwords which are defined in »PLC Designer« in
"Usergroup passwords“. x x x x
CurrentWrit
eAccessClien
tId DWORD ID of the visualization client which in a mulit-client
operation currently has the write access on the PLC
data
- - x x
CurrentClien
tId DWORD ID of the current visualization client - - x x
