L-force | PLC Designer
The Individual Components
DMS 3.2 EN 02/2011 TD29 211
6.5.10 'Edit' 'Input Assistant'
Shortcut:
This command provides a dialog box for choosing possible inputs at the current cursor
position in the editor window. In the left column choose the desired input category,
select the desired entry in the right column, and confirm your choice with OK. This
inserts your choice at this position.
The categories offered depend upon the current cursor position in the editor window,
i.e. upon that which can be entered at this point (e.g. variables, operators, POUs,
conversions, etc.).
If the option With arguments is active, then when the selected element is inserted,
the arguments to be transferred are specified with it, for example: function block fu1
selected, which defines the input variable var_in: fu1(var_in:=);
Insertion of function func1, which uses var1 and var2 as transfer parameters:
func1(var1,var2)
It is basically possible to switch between structured and unstructured display of the
available elements. This occurs through activation/deactivation of the Structured
Display option.
Note!
For inserting identifiers you also can use the Intellisense functionality.
