PLC Designer Visualization
720 DMS 3.2 EN 02/2011 TD29
Component
(+Data type) Effect Example
(the Object Name "vis1" has been
defined for the element)
corresponding entries
in configuration
dialog:
dwFontFlags :
DWORD; Font display.
Available flags:
1 italic
2 fett
4 underlined
8 canceled
+ combinations by
adding values
vis1.dwFontFlags:=10;
(Text is displayed blue and canceled)
- Cat. Text: Schrift |
Schriftschnitt
- Cat. Textvariables:
Fontflags
stFontName :
STRING; Change font vis1.stFontName:=’Arial’;
(Arial is used)
- Cat. Text: Schrift |
Schriftart
- Cat. Textvariables:
Fontname
nLineWidth : INT; Line width of the
frame (pixels)
vis1.nLWidth:=3;
(Frame width is 3 Pixels)
- Cat. Line width
dwFillColor :
DWORD; Fill color (definition
of colors see
subsequent to this
table) vis1.dwFillColor":=16#00FF0
000;
(Element ist im "Normalzustand" blau)
- Cat. Color: Color |
Inside
- Cat. Colorvariables:
Inside
dwFillColorAlarm :
DWORD; Fill color as soon as
bToggleColor gets
TRUE, see above)
(definition of colors
see subsequent to
this table) vis1.dwFillColorAlarm:=16#0
0808080;
(as soon as Variable togglevar gets
TRUE, the element will be displayed
grey-colored)
- Cat. Color: Alarm
color | Inside
- Cat. Colorvariables:
Inside Alarm
dwFrameColor:
DWORD; Frame color
(definition of colors
see subsequent to
this table)
vis1.dwFrameColor:=16#00FF0
000
; (Frame is blue-colored)
- Cat. Color: Color |
Frame
- Cat. Colorvariables:
Frame
dwFrameColorAla
rm: DWORD; Fill color as soon as
bFrameColor gets
TRUE, see above
(definition of colors
see subsequent to
this table) vis1.dwFrameColorAlarm:=16#
00808080
; (as soon as Variable
vis1.bToggleColor gets TRUE, the
frame will be displayed grey-colored)
- Cat. Color: Alarm
color | Frame
- Cat. Colorvariables:
Frame Alarm
dwFillFlags:
DWORD;
Color, as defined by
the color variables,
can be displayed or
ignored
0 = show color
>0 = ignore setting
vis1.dwFillFlags:=1;
(element gets invisible)
- Cat. Color: No color
inside +
No frame color
- Cat. Colorvariables:
Fillflags
