L-force | PLC Designer
The Individual Components
DMS 3.2 EN 02/2011 TD29 139
Category Files
Bitmap Files *.bmp (bitmaps for project POUs and visualizations)
Registry Entries Registry.reg (Entries for Automation Alliance, Gateway and SPS; the
following subtrees will be packed:
HKEY_LOCAL_MACHINE\SOFTWARE\3S-Smart Software Solutions
HKEY_LOCAL_MACHINE\SOFTWARE\AutomationAlliance"
Symbol Files *.sdb, *.sym (symbolic information)
Configuration files files used for PLC configuration (configuration files, device files, icons etc.):
e.g. *.cfg, *.con, *.eds, *.dib, *.ico ....
Target Files *.trg (target files in binary format for all installed targets)
*.txt (target files for the installed targets in text format, if available)
Local Gateway Gateway.exe, GatewayDDE.exe, GClient.dll, GDrvBase.dll, GDrvStd.dll,
GHandle.dll, GSymbol.dll, GUtil.dll, further DLLs in the gateway directory if
available
Language Files language files used for visualizations (*.vis, *.xml)
Bootproject Bootproject files .prg, .chk resp. the target
specific bootproject files.
To add any other files to the zip, press the button Other Files. The dialog 'Other files'
will open where you can set up a list of desired files.
Dialog box for adding other files for the Archive ZIP
Press the button Add to open the standard dialog for opening a file, where you can
browse for a file. Choose one and confirm with Open. The file will be added to the list
in the 'Other files' dialog. Repeat this for each file you want to add. To delete entries
from the list, press the button Remove. When the list of selected files is ok, close the
dialog with OK.
