Data types in PLC Designer
526 DMS 3.2 EN 02/2011 TD29
11.2.5 Structures
Structures are created as objects in the Object Organizer under the register card
Data types. They begin with the keywords TYPE and STRUCT and end with
END_STRUCT and END_TYPE.
The syntax for structure declarations is as follows:
TYPE :
STRUCT
.
.
END_STRUCT
END_TYPE
is a type that is recognized throughout the project and can be used
like a standard data type.
Interlocking structures are allowed. The only restriction is that variables may not be
placed at addresses (the AT declaration is not allowed!).
Example for a structure definition named Polygonline:
TYPE Polygonline:
STRUCT
Start:ARRAY [1..2] OF INT;
Point1:ARRAY [1..2] OF INT;
Point2:ARRAY [1..2] OF INT;
Point3:ARRAY [1..2] OF INT;
Point4:ARRAY [1..2] OF INT;
End:ARRAY [1..2] OF INT;
END_STRUCT
END_TYPE
