Inputs
Identifier/data type Information/possible settings
bExecute
BOOL
Rising edge starts the access
eDirection
LDM_tDIR
Access direction
LDM_READ - read
LDM_WRITE - write
sNodeAddr
STRING(255)
Topology address
'/' - access to parameters of the industrial PC
wCode
WORD
Code of the parameter (Lenze)
Then wIndex has to be set to 0
wIndex
WORD
Index of the parameter (CANopen)
Then wCode has to be set to 0
bySubIndex
BYTE
Subindex/subcode of the parameter
eDataType
LDM_tVT
Specification of the type of the parameter to be written
Example: LDM_VT_I2 : 2 bytes integer
Example: LDM_VT_I4 : 4 bytes integer
sDataW
STRING(255)
Value to be written (string) - table Connection between the inputs and
outputs and the data type
byDataW
BYTE
Value to be written (1*byte) - table Connection between the inputs and
outputs and the data type
wDataW
WORD
Value to be written (2*byte) - table Connection between the inputs and
outputs and the data type
dwDataW
WORD
Value to be written (4*byte) - table Connection between the inputs and
outputs and the data type
