'Insert' 'Label' in CFC
Symbol: Shortcut: +
This command is used to insert a label. The text offered "???" can be selected and
replaced by the jump label. In Online mode a RETURN label for marking the end of
POU is automatically inserted.
The jump is inserted using the command 'Insert 'Jump'.
'Insert' 'Return' in CFC
Symbol: Shortcut: +
This command is used to insert a RETURN command. Note that in Online mode a jump
label with the name RETURN is automatically inserted in the first column and after
the last element in the editor; in stepping, it is automatically jumped to before
execution leaves the POU.
'Insert' 'Comment' in CFC
Symbol: Shortcut: +
This command is used to insert a comment.
You obtain a new line within the comment with + .
'Insert' 'Input of box' in CFC
Shortcut: +
This command is used to insert an input at a box. The number of inputs is variable for
many operators (e.g. ADD can have two or more inputs).
To increase the number of inputs for such an operator by one, the box itself must be
selected
Insert' 'In-Pin' in CFC, 'Insert' 'Out-Pin'
Symbol:
These commands are available as soon as a macro is opened for editing. They are used
for inserting in- or out-pins as in- and outputs of the macro. They differ from the
normal in- and outputs of POUs by the way they are displayed and in that they have
no position index.
