The following entries can be generated:
• Entries in parameter lists of type 'Variables'
− from the declaration part of programs and global variables lists:
For a variable defined in a PROGRAM- or VAR_GLOBAL declaration an entry in a
parameter list of type 'Variables' can be created, if it is declared like described
in the following: (If the parameter list does not yet exist, it will be created
automatically)
Syntax:
{parameter list= [ = = ...further keys ] }
Example: Variable bvar is declared in a program. It should be entered in the
parameter list parlist1 (type 'Variables') with symbolic name bvar1, value 102,
index 16#1200 and subindex 16#2l.
VAR
bvar:INT{parameter list=parlist1 [name=bvar1 value=102
index=16#1200 subindex=16#1 ] };
END_VAR
− via a declaration in the VAR_CONFIG Interface:
There is the possibility to create an entry for a variable in a parameter list of
type 'Variables' by placing a pragma in a VAR_CONFIG window (independent of
variable configurations, which also are done in the VAR_CONFIG interface !):
(If the parameter list does not yet exist, it will be created automatically)
Syntax:
{parameter list= path= [ =
= ...further keys ] }
Path of the variable, for which the entry should be generated, e.g.
"PLC_PRG.act1.var_x"
Example: For variable var_x an entry is created in parameter list "varlist1",
symbolic name is "xvar".
VAR_CONFIG
{parameter list=varlist1 path=PLC_PRG.act1.var_x [
name=xvar ] }
END_VAR
