L-force | PLC Designer
The Individual Components
108 DMS 3.2 EN 02/2011 TD29
Show POU symbols: If this option is activated, in the module boxes which are inserted
to a graphic editor, additionally symbols will get displayed, if those are available in the
library folder as bitmaps. The name of the bitmap-file must be composed of the name
of the module and the extension ".bmp". Example: For module TON there is a symbol
file TON.bmp available. The box will be displayed as follows:
Note!
The settings will be stored in »PLC Designer«.
6.2.4 Options for the Desktop
If you choose this category in the Options dialog box, then you get the following
dialog box:
Options dialog box of the category Desktop
When an option is activated, a check appears in front of it.
Tool bar: The tool bar with the buttons for faster selection of menu commands
becomes visible underneath the menu bar.
Status bar: The status bar at the lower edge of the PLC Designer main window
becomes visible.
