Lenze PLC Designer PLC Designer (R2-x) - Manual (Page 544)

L-force | PLC Designer
Command Line-/Command File
542 DMS 3.2 EN 02/2011 TD29
Read-only access for particular objects :
object setreadonly
| Sets read-only access to a object; Define the object type and in case
of object types pou, dut, gvl, vis also the name of the object. Possible object types: pou, dut (data type), gvl (global variables list), vis (visualization), cnc (CNC object), liblist (Libraries), targetsettings,
toolinstanceobject (particular Tools instance), toolmanagerobject
(all instances in the Tools tree), customplconfig (PLC configuration), projectinfo (Project information), taskconfig (task configuration), trace, watchentrylist (Watch and Recipe Manager), alarmconfig
(Alarm configuration) e.g. "object setreadonly TRUE pou plc_prg" will set the PLC_PRG to read-only access Entering communications parameters (gateway, device): gateway local Sets the gateway on the local computer as the current gateway. gateway tcpip Sets the gateway in the specified remote computer as the current
gateway.
: TCP/IP address or hostname of the remote computer
: TCP/IP port of the remote gateway Important: Only gateways that have no password set can be
reached! device guid Sets the device with the specified GUID as the current device. GUID must have the following format: {01234567-0123-0123-0123-0123456789ABC} The curly brackets and the hyphens must appear at the specified
positions. device instance name> Sets the instance name for the current device to the name specified device parameter Assigns the specified value, which will then be interpreted by the device, to the parameter with the specified ID. System call: system Carries out the specified operating system command. Select target system: target Sets the target platform for the current project. If »PLC Designer« is
getting started with command line option "/notargetchange", only
by this command a target can be set. Pages: 1 … 542 543 544 545 546 … 844 wrong Brand wrong Model non readable See also other documents in the category Lenze Software: 9400 (954 pages) p300 (195 pages) I/O system 1000 (44 pages) 3241C (32 pages) PC-based automation (60 pages) DSD (496 pages) PLC Designer R3-x (159 pages) Engineer v2.21 (312 pages) PLC Designer ApplicationTemplate (PLC Designer R3-x) (177 pages) PLC Designer Migration PLC Designer (R2-x)-PLC Designer (R3-x) (30 pages) PLC Designer PLC Designer (R3-1) (1170 pages) PLC Designer PLC Designer (R2-x) CANopen for Runtime Systems (56 pages) PLC Designer PLC-Designer (R2-x) SoftMotion (290 pages) ApplicationTemplate PackML (PLC Designer R3-x) (99 pages) EASY Starter-ApplicationLoader (13 pages) ASY Starter Lenze OPC UA-Server (9 pages) 8400 motec (518 pages) 8400 TopLine (1760 pages) i700 (338 pages) 8400 HighLine (1576 pages) 8400 StateLine (1030 pages) 8400 BaseLine C (342 pages) 8400 BaseLine D (260 pages) E70ACxS Application Sample i700 (PLC Designer v3) (33 pages) E94AYFLF Digital frequency module (54 pages) E94ARNE Regenerative power supply (360 pages) E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) (679 pages) E94AxHE Technology Application Actuating drive - Speed (38 pages) E94AxHE Technology Application Actuating drive - Torque (34 pages) E94AxHE Technology Application CiA402 Device profile (232 pages) E94AxHE Technology Application Electronic gearbox (80 pages) E94AxHE Technology Application Positioning sequence control (78 pages) E94AxHE Technology Application Synchronism (80 pages) E94AxHE Technology Application Table positioning (50 pages) Loader L-force Loader (45 pages) L-force I/O System 1000 (99 pages) Function library LenzeIO1000Drv (64 pages) ETC Motion Control (428 pages) Function library CANopenSdoDrv (26 pages) Function library LenzeConversionBox (14 pages) ACU UPS for Industrial PCs (18 pages) PLC Designer V2.x (336 pages) IPC Operating System Windows CE Thin Client (26 pages) IPC Operating System Windows Embedded Standard 2009 (14 pages) Sitemap
Sets read-only access to a object; Define the object type and in case
of object types pou, dut, gvl, vis also the name of the object. Possible object types: pou, dut (data type), gvl (global variables list), vis (visualization), cnc (CNC object), liblist (Libraries), targetsettings,
toolinstanceobject (particular Tools instance), toolmanagerobject
(all instances in the Tools tree), customplconfig (PLC configuration), projectinfo (Project information), taskconfig (task configuration), trace, watchentrylist (Watch and Recipe Manager), alarmconfig
(Alarm configuration) e.g. "object setreadonly TRUE pou plc_prg" will set the PLC_PRG to read-only access Entering communications parameters (gateway, device): gateway local Sets the gateway on the local computer as the current gateway. gateway tcpip Sets the gateway in the specified remote computer as the current
gateway.
: TCP/IP address or hostname of the remote computer
: TCP/IP port of the remote gateway Important: Only gateways that have no password set can be
reached! device guid Sets the device with the specified GUID as the current device. GUID must have the following format: {01234567-0123-0123-0123-0123456789ABC} The curly brackets and the hyphens must appear at the specified
positions. device instance name> Sets the instance name for the current device to the name specified device parameter Assigns the specified value, which will then be interpreted by the device, to the parameter with the specified ID. System call: system Carries out the specified operating system command. Select target system: target Sets the target platform for the current project. If »PLC Designer« is
getting started with command line option "/notargetchange", only
by this command a target can be set. Pages: 1 … 542 543 544 545 546 … 844 wrong Brand wrong Model non readable See also other documents in the category Lenze Software: 9400 (954 pages) p300 (195 pages) I/O system 1000 (44 pages) 3241C (32 pages) PC-based automation (60 pages) DSD (496 pages) PLC Designer R3-x (159 pages) Engineer v2.21 (312 pages) PLC Designer ApplicationTemplate (PLC Designer R3-x) (177 pages) PLC Designer Migration PLC Designer (R2-x)-PLC Designer (R3-x) (30 pages) PLC Designer PLC Designer (R3-1) (1170 pages) PLC Designer PLC Designer (R2-x) CANopen for Runtime Systems (56 pages) PLC Designer PLC-Designer (R2-x) SoftMotion (290 pages) ApplicationTemplate PackML (PLC Designer R3-x) (99 pages) EASY Starter-ApplicationLoader (13 pages) ASY Starter Lenze OPC UA-Server (9 pages) 8400 motec (518 pages) 8400 TopLine (1760 pages) i700 (338 pages) 8400 HighLine (1576 pages) 8400 StateLine (1030 pages) 8400 BaseLine C (342 pages) 8400 BaseLine D (260 pages) E70ACxS Application Sample i700 (PLC Designer v3) (33 pages) E94AYFLF Digital frequency module (54 pages) E94ARNE Regenerative power supply (360 pages) E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) (679 pages) E94AxHE Technology Application Actuating drive - Speed (38 pages) E94AxHE Technology Application Actuating drive - Torque (34 pages) E94AxHE Technology Application CiA402 Device profile (232 pages) E94AxHE Technology Application Electronic gearbox (80 pages) E94AxHE Technology Application Positioning sequence control (78 pages) E94AxHE Technology Application Synchronism (80 pages) E94AxHE Technology Application Table positioning (50 pages) Loader L-force Loader (45 pages) L-force I/O System 1000 (99 pages) Function library LenzeIO1000Drv (64 pages) ETC Motion Control (428 pages) Function library CANopenSdoDrv (26 pages) Function library LenzeConversionBox (14 pages) ACU UPS for Industrial PCs (18 pages) PLC Designer V2.x (336 pages) IPC Operating System Windows CE Thin Client (26 pages) IPC Operating System Windows Embedded Standard 2009 (14 pages) Sitemap
Sets read-only access to a object; Define the object type and in case
of object types pou, dut, gvl, vis also the name of the object.
Possible object types: pou, dut (data type), gvl (global variables list),
vis (visualization), cnc (CNC object), liblist (Libraries), targetsettings,
toolinstanceobject (particular Tools instance), toolmanagerobject
(all instances in the Tools tree), customplconfig (PLC configuration),
projectinfo (Project information), taskconfig (task configuration),
trace, watchentrylist (Watch and Recipe Manager), alarmconfig
(Alarm configuration)
e.g. "object setreadonly TRUE pou plc_prg" will set the PLC_PRG to
read-only access
Entering communications parameters (gateway, device):
gateway local Sets the gateway on the local computer as the current gateway.
gateway tcpip Sets the gateway in the specified remote computer as the current
gateway.
Important: Only gateways that have no password set can be
reached!
device guid Sets the device with the specified GUID as the current device.
GUID must have the following format:
{01234567-0123-0123-0123-0123456789ABC}
The curly brackets and the hyphens must appear at the specified
positions.
device instance name> Sets the instance name for the current device to the name specified
device parameter Assigns the specified value, which will then be interpreted by the
device, to the parameter with the specified ID.
System call:
system Carries out the specified operating system command.
Select target system:
target Sets the target platform for the current project. If »PLC Designer« is
getting started with command line option "/notargetchange", only
by this command a target can be set.
