L-force | PLC Designer

PLC Designer Visualization

682

DMS 3.2 EN 02/2011 TD29

20.3.1

'Insert' 'Rectangle'

Symbol:

With the command you can insert a rectangle as an element into your present
visualization. (Use, see Visualization Elements, Insert)

20.3.2

'Insert' 'Rounded Rectangle'

Symbol:

With the command you can insert a rectangle with rounded corners as an element in
your present visualization. (Use, see Visualization Elements, Insert).

20.3.3

'Insert' 'Ellipse'

Symbol:

With the command you can insert a circle or an ellipse as an element in your present

visualization. (Use, see Visualization Elements, Insert).

20.3.4

'Insert' 'Polygon'

Symbol:

With the command you can insert a polygon as an element in your present
visualization. (Use, see Visualization Elements, Insert).

20.3.5

'Insert' 'Polyline'

Symbol:

With the command you can insert a line as an element into your current visualization.
(Use, see Visualization Elements, Insert).

20.3.6

'Insert' 'Curve'

Symbol:

With the command you can insert a Bezier curve as an element into your current
visualization. (Use, see Visualization Elements, Insert).
