Lenze PLC Designer PLC Designer (R2-x) - Manual (Page 721)

L-force | PLC Designer
PLC Designer Visualization
DMS 3.2 EN 02/2011 TD29 719
Component
(+Data type) Effect Example
(the Object Name "vis1" has been
defined for the element)
corresponding entries
in configuration
dialog:
bInvisible : BOOL; Element is visible /
invisible
vis1.visible:=TRUE;
(element is invisible)
- Cat. Color: No color
inside +
No frame color
- Cat. Colorvariables:
Fillcolor +
Framecolor
stTextDisplay :
STRING; Text is displayed in
element vis1.TextDisplay:='ON /
OFF';
element is inscribed with this text
- Cat. Text: entry at
'Content'
bToggleColor :
BOOL; color change when
toggling between
TRUE and FALSE
vis1.bToggleColor:=alarm_va
r;
(As soon as alarm_var gets TRUE, the
element gets the color defined via the
components dwFillColorAlarm,
dwFrameColorAlarm resp. via the
settings in category 'Colorvariables' or
'Color'.
- Cat. Input: Toggle
variable +
- Cat. Variables:
Change color
bInputDisabled:
BOOL; if FALSE: Inputs in
category 'Input' are
ignored vis1.bInputDisabled:=FALSE;
(no input is possible for this elementt)
- Cat. Variables:
'Disable Input'
stTooltipDisplay:S
TRING; Text of the tooltip vis1.stTooltipDisplay:='Swi
tch for .....'; - Cat. Text for Tooltip:
Entry in
'Content:'
dwTextFlags:DW
ORD; Text position:
1 left justified
2 right justified:
4 centered
horizontally
8 top
10 bottom
20 centered
vertically
Note: Always set a
horizontal and a
vertical position
(addition of values)!
vis1.dwTextFlags:=24;
(Text will be placed in the center of
the element (4 + 20)
- Cat. Text: Horizontal
and
Vertical options
- Cat. Textvariables:
Textflags
dwTextColor :
DWORD;
Text color
(definition of colors
see subsequent to
this table)
vis1.dwTextColor :=
16#00FF0000;
(Text is blue-colored)
- Cat. Text: Font |
Color
- Cat. Textvariables:
Textcolor
nFontHeight : INT; Font height in Pixel.
should be in range
10-96
vis1.nFontHeight:=16;
(Text height is 16 pt)
- Cat. Text: Font |
Grad'
- Cat. Textvariables:
Font heigth
