10.2.3 Addressing bits in variables
In integer variables individual bits can be accessed. For this, the index of the bit to be
addressed is appended to the variable, separated by a dot. The bit-index can be given
by any constant. Indexing is 0-based.
Note!
Bitaccess in Direct variables is not allowed.
Example:
a : INT;
b : BOOL;
...
a.2 := b;
The third bit of the variable a will be set to the value of the variable b.
If the index is greater than the bit width of the variable, the following error message is
issued: Index '' outside the valid range for variable ''!
Bit addressing is possible with the following variable types: SINT, INT, DINT, USINT,
UINT, UDINT, BYTE, WORD, DWORD.
If the variable type does not allow it, the following error message is issued: "Invalid
data type '' for direct indexing"
A bit access must not be assigned to a VAR_IN_OUT variable!
Bitaccess via a global constant:
If you have declared a global constant, which defines the bit-index, you can use this
constant for a bitaccess.
Note!
The project option 'Replace constants' (category Build) must be activated !
