PLC Designer Files
DMS 3.2 EN 02/2011 TD29 567
File
Exten
sion Example Description Format Path(Default)
*.asd project01.asd save file (temporary, 'Auto
save', 'Auto save before
compile')
binary project directory
*.asl lib01.asl save file for a library opened
as project in »PLC Designer«
(temporary, 'Auto save', 'Auto
save before compile')
binary library resp.
project directory
*.bak project01.bak backup file for project
(permanent, 'Create backup')
binary project directory
*.prg
*.bin
default.prg
project01.prg boot project, file name
depending on target binary target system
(created online)
project directory
(created offline)
*.chk default.chk
project01.chk checksum for boot projekt
code binary target system
(created online)
project directory
(created offline)
*.ini plcdesigner.ini ini-file for various PLC
Designer settings Text with
plcdesigner.exe
*.dfr default.dfr
project01.dfr
frame file (Printer setup) binary with
plcdesigner.exe
*.asm code386.asm assembler-Listing of the
created project code Text compile directory
*.lst project01.lst assembler-Listing of the
created project code Text compile directory
*.bpl project01.bpl debug-files (breakpoint-
information)
Text compile directory
*.st PLC_PRG.st debug-files, implicit ST-code Text compile directory
*.ma
p project01.map map-file; information on
memory organization and
variable locations Text compile directory
*.hex
*.h86
project01.hex (Output)
resp. standard.hex (Lib) .hex for Intel or Motorola,
.h86 for Intel; compiler
output or input for external
library
Intel or
Motorola hex-
files
compile directory
resp. library
directory
*.trd projectxy0.trd trend logging (number befor
the dot is counted up, if file is
full and another must be
created)
Text project directory
*.log projectxy.log log file (Log) binary project directory
