20.7 Visualization Object, Configure...
Besides the configuration of the individual visualization elements also the
visualization object as a whole can get configured. This is possible concerning the
settings for frame, language, grid, background, placeholders etc. as well as the
assignment of special hotkey definitions (keyboard usage), which should be valid for
exactly one visualization object. These settings are done in the visualization editor via
commands of the 'Extras' menu.
Besides that outside of the editor you can do some settings in the Properties dialog of
the visualization object, which concern the Usage as Target- or Web-Visualization or
as Master layout.
Regard that in the project options a separate directory can be defined for visualization
files.
Image files can be used for the background (static) of a visualization resp. in "bitmap"
elements (static or dynamic use).
20.7.1 'Extras' 'Settings'
When this command is used, a dialog box will open in which you can make certain
settings that affect the display and language in the visualization as well as the check
of the visualization variables.
Note!
The categories Display, Frame and Language also can be edited in the online mode.
Category Display : Enter a zoom factor into the field Zoom of between 10 and 500 % in
order to increase or decrease the size of the visualization display. If option Element
numbers is activated, in each visualization element its number will be displayed, via
which it is managed in the Element lst.
In the 'Text' area via button Font the standard dialog for selecting a font can be used
for defining the font for the current visualization. This font will be automatically
applied to all visualization elements, which do not have got a different font explicitly
assigned via the element configuration (categorie Text). Via button Standard-Font the
project font, which is defined in the Project Options, can be set as Visualization font,
which also will only effect those elements without individual font definitions. Even
those elements however can get assigned the currently valid standard font by the
Standard-Font button in their element configuration dialog.
