Lenze PLC Designer PLC Designer (R2-x) - Manual (Page 313)

L-force | PLC Designer
Editors in PLC Designer
DMS 3.2 EN 02/2011 TD29 311
'Insert' 'Falling edge detection' in LD
Symbol:
This commands inserts a F_TRIG function block, which serves to detect a rising edge
(TRUE -> FALSE) at the incoming signal. The same is true as for command 'Insert'
'Function Block' which can be used to insert any available function block.
'Insert' 'Timer (TON)' in LD
Symbol:
This command inserts a timer function block of type TON. This serves to get a turn-on
delay (delayed passing on of the incoming signal). For the inserting the same is true as
for command 'Insert' 'Function Block', which also could be used to insert a TON
module.
'Insert' 'Jump' in LD
With this command you can insert a parallel jump in the selected LD editor, in parallel,
at the end of the previous coils. If the incoming line delivers the value "On", then the
jump will be executed to the indicated label.
The marked position must be the connection between the contacts and the coils or a
coil.
The jump is present with the text "???". You can click on this text and make a change
in the desired label.
'Insert' 'Return' in LD
In the LD editor, you can use this command to insert a Return instruction in parallel at
the end of the previous coils. If the incoming line delivers the value "On," then the
processing of the POU in this network is broken off.
The marked position must be the connection between the contacts and the coils or a
coil.
'Extras' 'Paste after' in LD
Use this command in the LD editor to paste the contents of the clipboard as serial
contact below the marked position. This command is only possible if the contents of
the clipboard and the marked position are networks comprised of contacts.
