AT-DC2552SX Switch Command Line Interface User’s Guide
Section V: Security and Traffic Control 513
SHOW CLASS-MAP
Syntax
show class-map name
Parameter
name
Specifies the name of a class map. The name is case-sensitive
and can be up to 63 alphanumeric characters.
Modes
Privileged Exec
Description
Use this command to display the settings of the specified class map.
When you do not specify a class name, the command displays all the class
maps defined on the switch. See Figure 76 for an example of this
command.
Figure 76. SHOW CLASS-MAP Command
The fields are described in Table 80.
Table 80. SHOW CLASS-MAP Command
Field Description
CLASS-MAP-NAME Displays the name of a class map.
QOS-ACCESS-LIST
NAME Displays the name of hardware ACL set by
the MATCH ACCESS-GROUP command.
Match vlan Displays the VID set by the MATCH VLAN
command.
Match IP DSCP Displays the value of DSCP set by the
MATCH DSCP command.
CLASS-MAP-NAME: cmap1
Match IP DSCP: 10
Match Mac Type: 12ucast
CLASS-MAP-NAME: cmap2
Match IP DSCP: 20
Match Mac Type: 12ucast
