AT-DC2552SX Switch Command Line Interface User’s Guide
Section II: Layer 2 Switching 267
SHOW MIRROR
Syntax
show mirror
Parameters
None
Mode
Privileged Exec mode
Description
Use this command to display the settings of the mirror port on the switch.
See Figure 48 for an example.
Figure 48. SHOW MIRROR
The fields are described in Table 44.
Table 44. SHOW MIRROR Command
Field Description
Mirror Test Port Name Displays the port ID of the mirror port.
Mirror option Indicates that Port Mirroring is enabled or
disabled.
Mirror Test Port Name: port1.0.40
Mirror option: Enabled
Mirror direction: both
Monitored Port Name: port1.0.41
Mirror Test Port Name: port1.0.40
Mirror option: Enabled
Mirror direction: both
Monitored Port Name: port1.0.42
Mirror Test Port Name: port1.0.40
Mirror option: Enabled
Mirror direction: both
Monitored Port Name: port1.0.43
Mirror Test Port Name: port1.0.40
Mirror option: Enabled
Mirror direction: both
Monitored Port Name: port1.0.44
