AT-DC2552SX Switch Command Line Interface User’s Guide
Section II: Layer 2 Switching 355
SHOW SPANNING-TREE MST CONFIG
Syntax
show spanning-tree mst config
Parameters
None
Mode
Privileged Executive Mode
Description
Use this command to display the MSTP configuration on the switch. Within
this command display, switches with the same settings belong to the same
MST region.
Note
This command is applicable only when MSTP is enabled.
See Figure 61 for an example of this command.
Figure 61. SHOW SPANNING-TREE MST CONFIG Command
The fields are described in Table 61.
Table 61. SHOW SPANNING-TREE MST CONFIG Command
Field Description
Format Id Displays the value of the format selector. It
shows always “0,” meaning MSTP.
Name Displays the name of MST region.
%
% MSTP Configuration Information for bridge 0:
% --------------------------------------------------------
%
Format Id : 0
% Name : Test
% Revision Level : 1
% Digest : 0x9357EBB7A8D74DD5FEF4F2BAB50531AA
% --------------------------------------------------------
