AT-DC2552SX Switch Command Line Interface User’s Guide
Section II: Layer 2 Switching 293
SHOW ETHERCHANNEL SUMMARY
Syntax
show etherchannel summary
Parameters
None
Mode
Privileged Exec mode
Description
Use this command to display the states of the member ports of the LACP
trunk groups. See Figure 53 for an example of the command output.
Figure 53. SHOW ETHERCHANNEL SUMMARY Command
The fields are described in Table 50.
Table 50. SHOW ETHERCHANNEL SUMMARY Command
Field Description
Aggregator Indicates the ID number of the trunk group.
Admin Key Indicates the value that is used to generate
the LACP port key.
Oper Key Indicates the LACP port key.
Aggregator # 2 .... po2
Admin Key: 0xff0d - Oper Key: 0x0d0d
Link: Port1.0.13 sync
Link: Port1.0.14 sync
Aggregator # 1 .... po1
Admin Key: 0xff19 - Oper Key: 0x1919
Link: Port1.0.25 disabled
Link: Port1.0.26 sync
Link: Port1.0.27 disabled
Link: Port1.0.28 disabled
