Appendix - 103
MELSEC-Q
APPENDICES
Buffer memory address
Axis 1 Axis 2 Axis 3 Axis 4
Item Memory area
1541 1641 1741 1841
Cd.31 Simultaneous starting axis start data No.
(axis 2 start data No.)
1542 1642 1742 1842
Cd.32 Simultaneous starting axis start data No.
(axis 3 start data No.)
1543 1643 1743 1843
Cd.33 Simultaneous starting axis start data No.
(axis 4 start data No.)
1544 1644 1744 1844 Cd.34 Step mode
1545 1645 1745 1845 Cd.35 Step valid flag
1546 1646 1746 1846 Cd.36 Step start information
1547 1647 1747 1847 Cd.37 Skip command
1548 1648 1748 1848 Cd.38 Teaching data selection
1549 1649 1749 1849 Cd.39 Teaching positioning data No.
1550 1650 1750 1850 Cd.40 ABS direction in degrees
A
x
is control data
1900 Cd.1 Flash ROM write request
1901 Cd.2 Parameter initialization request
1905 Cd.41 Deceleration start flag valid
1907
Cd.42 Stop command processing for deceleration
stop selection
Sy
stem C
ontrol data
C
ontrol data
