9 - 50
MELSEC-Q
9 MAJOR POSITIONING CONTROL
Axis
Setting item
Axis 1
(reference
axis) setting
example
Axis 2
(interpolation
axis) setting
example
Axis 3
(interpolation
axis) setting
example
Setting details
Da.1 Operation pattern
Positioning
complete
– –
Set "Positioning complete" assuming the next
positioning data will not be executed.
Da.2 Control method Fixed-feed 3 – – Set 3-axis fixed-feed control.
Da.3
Acceleration time
No.
1 – –
Designate the value set in " Pr.25
Acceleration time 1" as the acceleration time
at start.
Da.4
Deceleration time
No.
0 – –
Designate the value set in " Pr.10
Deceleration time 0" as the deceleration time
at deceleration.
Da.5
Axis to be
interpolated
– – –
Setting not required (setting value will be
ignored).
When axis 1 is used as a reference axis, the
interpolation axes are axes 2 and 3.
Da.6
Positioning address/
movement amount
10000.0
µ
m 5000.0
µ
m 6000.0
µ
m
Set the positioning address. (Assuming "mm"
is set in " Pr.1 Unit setting".)
Da.7 Arc address – – –
Setting not required (setting value will be
ignored).
Da.8 Command speed
6000.00
mm/min
– – Set the speed during movement.
Da.9 Dwell time 500ms – –
Set the time the machine dwells after the
positioning stop (pulse output stop) to the
output of the positioning complete signal.
A
x
is 1 Positioning data N
o
. 1
Da.10 M code 10 – –
Set this when other sub operation commands
are issued in combination with the No. 1
positioning data.
Refer to Section 5.3 "List of positioning data" for information on the setting details.
POINTS
(1) When the "reference axis speed" is set during 3-axis fixed-feed control, set so the major axis side
becomes the reference axis. If the minor axis side is set as the reference axis, the major axis side
speed may exceed the " Pr.8 Speed limit value".
(2)Refer to Section 9.1.6 "Interpolation control" for the reference axis and interpolation axis
combinations.
