Appendix - 62
MELSEC-Q
APPENDICES
Monitor data
Item A1SD75 QD75
In test mode flag Md.1
Module name Md.2 –
OS type Md.3 –
OS version Md.4 –
Clock data (hour: minute) Md.5 –
Clock data (second: 100 ms) Md.6 –
Start axis (QD75: Md. 3 Start information) Md.7 Md.3
Operation type (QD75: Md. 4 Start No.) Md.8 Md.4
Start Hour: minute (QD75: Md. 5 Start Hour) Md.9 Md.5
Start Second: 100 ms (QD75: Md. 6 Start Minute: second) Md.10 Md.6
Error judgment Md.11 Md.7
Start history pointer
Start history
Md.12 Md.8
Start axis Md.13 –
Operation type Md.14 –
Start Hour: minute Md.15 –
Start Second: 100 ms Md.16 –
Error judgment Md.17 –
Start history storage during error
Start history during
errors
Md.18 –
Axis in which the error occurred Md.19 Md.9
Axis error No. Md.20 Md.10
Axis error occurrence Hour: minute
(QD75: Md. 11 Axis error occurrence (Hour))
Md.21 Md.11
Axis error occurrence Second: 100ms
(QD75: Md. 12 Axis error occurrence (Minute: second))
Md.22 Md.12
Pointer
Error history
Md.23 Md.13
Axis in which the warning occurred Md.24 Md.14
Axis warning No. Md.25 Md.15
Axis warning occurrence Hour: minute
(QD75: Md. 16 Axis warning occurrence (Hour))
Md.26 Md.16
Axis warning occurrence Second: 100ms
(QD75: Md. 17 Axis warning occurrence (Minute: second))
Md.27 Md.17
Pointer
Warning history
Md.28 Md.18
