Appendix - 100
MELSEC-Q
APPENDICES
Buffer memory address
Common to axes 1, 2, 3, and 4
Item
Memory
area
1200 Md.1 In test mode flag
1201
1202
1203
1204
1205
1206
1207
1208
1209
1210
1211
Not used
(0) (1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14) (15) (Pointer No.)
1212 1217 1222 1227 1232 1237 1242 1247 1252 1257 1262 1267 1272 1277 1282 1287 Md.3 Start information
1213 1218 1223 1228 1233 1238 1243 1248 1256 1258 1263 1268 1273 1278 1283 1288 Md.4 Start No.
1214 1219 1224 1229 1234 1239 1244 1249 1254 1259 1264 1269 1274 1279 1284 1289 Md.5 Start (Hour)
1215 1220 1225 1230 1235 1240 1245 1250 1255 1260 1265 1270 1275 1280 1285 1290 Md.6 Start (Minute: second)
1216 1221 1226 1231 1236 1241 1246 1251 1256 1261 1266 1271 1276 1281 1286 1291 Md.7 Error judgment
1292 Md.8 Start history pointer
Start H
istory
(0) (1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14) (15) (Pointer No.)
1293 1297 1301 1305 1309 1313 1317 1321 1325 1329 1333 1337 1341 1345 1349 1353
Md.9 Axis in which the error
occurred
1294 1298 1302 1306 1310 1314 1318 1322 1326 1330 1334 1338 1342 1346 1350 1354 Md.10 Axis error No.
1295 1299 1303 1307 1311 1315 1319 1323 1327 1331 1335 1339 1343 1347 1351 1355
Md.11 Axis error occurrence
(Hour)
1296 1300 1304 1308 1312 1316 1320 1324 1328 1332 1336 1340 1344 1348 1352 1356
Md.12 Axis error occurrence
(Minute: second)
1357 Md.13 Error history pointer
Error His
tory
(0) (1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14) (15) (Pointer No.)
1358 1362 1366 1370 1374 1378 1382 1386 1390 1394 1398 1402 1406 1410 1414 1418
Md.14 Axis in which the
warning occurred
1359 1363 1367 1371 1375 1379 1383 1387 1391 1395 1399 1403 1407 1411 1415 1419
Md.15 Axis warning No.
1360 1364 1368 1372 1376 1380 1384 1388 1392 1396 1400 1404 1408 1412 1416 1420
Md.16 Axis warning
occurrence (Hour)
1361 1365 1369 1373 1377 1381 1385 1389 1393 1397 1401 1405 1409 1413 1417 1421
Md.17 Axis warning
occurrence
(Minute: second)
1422 Md.18 Warning history pointer
W
a
rnin
g history
1424
1425 Md.19 No. of write accesses to
flash ROM
Sy
stem monitor data
M
onitor data
