Melsec-q, 3) output (for qd75d1) – MITSUBISHI ELECTRIC Mitsubishi Programmable Logic Controller QD75D User Manual
Page 72
3 - 24
MELSEC-Q
3 SPECIFICATIONS AND FUNCTIONS
(2) Output (For QD75P1)
External wiring
Pin No.
Internal circuit
Signal name
Need for wiring
1
1A13
Deviation counter clear
CLEAR
1A14
Common
CLEAR COM
1A15
PULSE F
1A16
CW
A phase
PULSE
PULSE COM
1A17
PULSE R
1A18
CCW
B phase
SIGN
PULSE COM
(3) Output (For QD75D1)
External wiring
Pin No.
Internal circuit
Signal name
Need for wiring
1
1A13
Deviation counter clear
CLEAR
1A14
Common
CLEAR COM
1A15
PULSE F+
1A16
CW
A phase
PULSE
PULSE F–
1A17
PULSE R+
1A18
CCW
B phase
SIGN
PULSE R–
2
2
Differential driver
common terminal
SG
1 :
The symbols in Need for wiring column indicate the following meanings:
•
: Wiring is necessary for positioning.
•
: Wiring is necessary depending on the situation.
2 :
A terminal block at the bottom of the module. (Refer to Section 4.1.2)
