5 - 120
MELSEC-Q
5 DATA USED FOR POSITIONING CONTROL
Setting item Setting details
•
Use this data item to set the amount of movement by inching.
•
The machine performs a JOG operation if "0" is set.
•
Set a value within the following range:
Pr.1
mm
(
×
10
-1
µm)
inch
(
×
10
-5
inch)
degree
(
×
10
-5
degree)
pulse
(pulse)
Setting range 0 to 65535 0 to 65535 0 to 65535 0 to 65535
Cd.16 Inching movement amount
•
Use this data item to set the JOG speed.
•
Set a value within the following range:
Pr.1
mm
(
×
10
-2
mm/min)
inch
(
×
10
-3
inch/min)
degree
(
×
10
-3
degree/min)
pulse
(pulse/s)
Setting range
0 to
2000000000
0 to
2000000000
0 to
2000000000
0 to 1000000
Cd.17 JOG speed
Cd.18 Interruption request during
continuous operation
•
To interrupt a continuous operation, set "1" to this data item.
•
After processing the interruption request ("1"), the QD75 automatically resets the
value to "0".
