Appendix - 57
MELSEC-Q
APPENDICES
Buffer memory address
A1SD75 QD75 Items of A1SD75
Axis 1 Axis 2 Axis 3 Axis 1 Axis 2 Axis 3
Cd.1 Clock data setting (hour) 1100 –
Cd.2 Clock data setting (minute, second) 1101 –
Cd.3 Clock data writing 1102 –
Cd.4 Target axis 1103 –
Cd.5 Positioning data No. 1104 –
Cd.6 Write pattern 1105 –
Cd.7 Read/write request 1106 –
Cd.8 Read/write positioning data I/F 1108 to 1137 –
Cd.9 Flash ROM write request 1138 1900
Cd.10 Parameter initialization request 1139 1901
Cd.11 Positioning start No. 1150 1200 1250 1500 1600 1700
Cd.12 Axis error reset 1151 1201 1251 1502 1602 1702
Cd.13 Restart command 1152 1202 1252 1503 1603 1703
Cd.14 M code OFF request 1153 1203 1253 1504 1604 1704
Cd.15 New current value
1154
1155
1204
1205
1254
1255
1506
1507
1606
1607
1706
1707
Cd.16 New speed value
1156
1157
1206
1207
1256
1257
1514
1515
1614
1615
1714
1715
Cd.17 Speed change request 1158 1208 1258 1516 1616 1716
Cd.18 Positioning operation speed override 1159 1209 1259 1513 1613 1713
Cd.19 JOG speed
1160
1161
1210
1211
1260
1261
1518
1519
1618
1619
1718
1719
Cd.20 Speed-position switching enable flag 1163 1213 1263 1528 1628 1728
Cd.21 Speed-position switching control movement
amount change register
1164
1165
1214
1215
1264
1265
1526
1527
1626
1627
1726
1727
Cd.22 Manual pulse generator enable flag 1167 1217 1267 1524 1624 1724
Cd.23 Manual pulse generator 1 pulse input
magnification
1168
1169
1218
1219
1268
1269
1522
1523
1622
1623
1722
1723
Cd.24 OPR return request flag OFF request 1170 1220 1270 1521 1621 1721
Cd.25 External start valid
(QD75: Cd. 8 External command valid)
1171 1221 1271 1505 1605 1705
Cd.26 Step valid flag 1172 1222 1272 1545 1645 1745
Cd.27 Step mode 1173 1223 1273 1544 1644 1744
Cd.28 Step start information
1174 1224 1274 1546 1646 1746
Cd.29 Skip command 1175 1225 1275 1547 1647 1747
Cd.30 New torque value 1176 1226 1276 1525 1625 1725
Cd.31 Positioning starting point No. 1178 1228 1278 1501 1601 1701
Cd.32 Interrupt request during continuous operation 1181 1231 1281 1520 1620 1720
Cd.33 New acceleration time value
1184
1185
1234
1235
1284
1285
1508
1509
1608
1609
1708
1709
