Page 581: Tunnel commands tunnel
Tunnel Commands
XSR CLI Reference Guide 14-127
Mode
Internet Protocol Interface configuration:
XSR(config-int
Example
This example redirects multicast traffic to the remote tunnel server:
XSR(config)#interface vpn 57 multi-point
XSR(config-int
service-policy
This command attaches a policy map to an VPN output or input interface. You can attach a single
policy map to one or more interfaces.
Syntax
service-policy [input | output] policy-map-name
Syntax of the “no” Form
The no form of the command removes a policy map from the interface:
no service-policy [input | output]
Mode
Interface configuration:
XSR(config-if
Example
The following example attaches service policy VPNpolicy to VPN output interface 1:
XSR(config)#interface vpn 1
XSR(config-int
Tunnel Commands
tunnel
This sub‐command of
interface vpn
names a tunnel created at boot time that links this VPN
interface with another VPN gateway. The VPN interface, with its tunnel, is equivalent to a point‐
to‐point interface. Issuing the command acquires Tunnel configuration mode, making available
the following sub‐commands:
•
set active -
Enables the VPN tunnel. Refer to
•
set heartbeat -
Monitors tunnel connectivity.
definition.
•
set peer -
Specifies the physical IP address of the remote VPN gateway. Refer to
policy-map-name
Attaches the specified policy map onto the output port.
