PPP Debug, Clear and Show Commands
8-102 Configuring the Point-to-Point Protocol
Mode
EXEC or Global configuration: XSR> or XSR(config)#
Sample Output
The following output is produced by this command:
Serial 1/0 is Admin Up / Oper Up
Internet address is 25.25.25.3, subnet mask is 255.255.255.0
LCP State: OPENED
IPCP State: OPENED
Multilink State: OPENED
show ppp interface
This command displays all configured PPP instances, the interface they belong to and their status.
To issue this command correctly, follow the guidelines below:
• Issuing the show ppp interface command without any other parameter displays link status,
statistics and configuration for all interfaces running PPP.
• The show ppp interface type command displays link status, statistics and settings for any
interface type running PPP.
• The show ppp interface type number command displays link status, statistics and
configuration for the interface type number.
• The show ppp interface dialer number [multi-class serial] command displays
Dialer statistics with Serial and Multiclass options.
• The show ppp interface multilink number [bap | memberlink | multi-class]
command displays multilink statistics with various options.
Syntax
show ppp interface card/port [type number options]
The Serial port card, port, sub‐interface, and channel numbers are expressed as follows:
card/port The NIM number and PPP WAN port:channel number to view associated link
status, statistics and settings.
type The interface type PPP is running on including: Dialer (0 to 255), Multilink (1 to
32767), or Serial (see below).
number Card/port numbers or Card/port:channel number.
option memberlink, mlpppgroup (MLPPP only), multi‐class, or bap (MLPPP only)
statistics.
0 Console port.
<1-2>/<0-3> Card and port number.
<1-2>/<0-3>.<1-30> Card, port, sub‐interface number.
<1-2>/<0-3>:<0-31> Card, port and channel number.
<1-2>/<0-3>:<0-31>.<1-30> Card, port, channel and sub‐interface number
