PPP Commands
XSR CLI Reference Guide 8-85
Syntax
interface type slot_num card_num port_num sub-interface_num
Slots, cards, ports, and sub‐interfaces are expressed as follows on the CLI:
Syntax of the “no” Form
The no command deletes the interface:
no interface serial port_num interface_num
Mode
Global configuration: XSR(config)#
Examples
This example selects interface serial 1/0 and sets PPP encapsulation:
type ATM, BRI, Dialer, Fast/GigabitEthernet, Loopback, Multilink, Serial or VPN
port.
slot_num The NIM number ranging from 0 to 6 depending on the XSR model.
card_num The NIM card number ranging from 1 to 2 depending on the NIM installed in
the slot.
port_num The physical port number ranging from: 0 (ATM), 0 to 1 (BRI), 0 to 255 (Dialer
& VPN), 0 to 15 (Loopback), 1 to 32767 (Multilink), 0 to 3 (Serial), 1 to 2
(FastEthernet), 1 to 3 (GigabitEthernet), and 0 (Console).
If a Serial port resides on a T1/E1 port, then channel group data must be
added at the end of the string to mark which channel group of the T1/E1 port
will be set:
card_num/NIM_num/ port_within_NIM: [channel‐group_num].
For example, 0/2/1:15 sets channel‐group 15 of the T1 or E1 port 1 in NIM slot
2 on the motherboard.
sub-
interface_num Number ranging from 1 to 30 (ATM, BRI & Serial), and 1 to 64 (Fast/
GigabitEthernet).
0 The console port. (Only on the XSR 1800 series)
<0-0>/<1-2>/<0-3> Slot, card, and port number.
<1-2>/<0-3> Card and port number.
<1-2>/<0-3>.<1-30> Card, port and sub‐interface number.
<1-2>/<0-3>:<0-31> Card, port and channel number.
<1-2>/<0-3>:<0-31> .<1-30> Card, port, channel and sub‐interface number.
Note: Leading zeros defined in interface_num can be omitted. For example, 0/1/2 is equivalent to 1/2.
Note: You cannot directly delete a Serial interface assigned to a T1/E1 channel group. You must
instead delete a channel group to delete the Serial port.
