Verilink 9000 Series (34-00271) Product Manual - Manual (Page 329)

NMCS Screens 307
Trusted Neighbors
Table Parameters
The Trusted Neighbors menu (Figure 18-9) can be used to store RIP information
only from a specific router. This allows the router to reject any RIP information
coming from non-Trusted Neighbors. Only information coming from Trusted
Neighbors is kept by the router.
To add or modify trusted neighbors from the main trusted neighbors menu, press F3
or F2 and Figure 18-6 appears. To list all configured trusted neighbors, press F4.
Defaults are shown underlined.
Line Module
This field indicates the line module number of the port currently displayed.
Entering a different line module number and pressing F10 transfers the screen to
the same port on the new line module.
Trusted Neighbor Number
The Trusted Neighbor Number must be unique and range from 1 to 255.
IP Address of Trusted Neighbor
This is the IP Address of the trusted device. See Table 18-1 on page 295 for
reserved and available IP addresses.
TXPORT INTELLINET Configuration Program
Configuration
ADD Trusted Neighbor menu
Line Module
Trusted Neighbor number [001]
IP Address Of Trusted Neighbor [ ].[ ].[ ].[ ]
F1=Hlp F2=Mod F3=Add F4=List F5=Clr F6=DelAll F7=Copy F8=Jmp F9=Prev F10=Next
Figure 18-9 Trusted Neighbors Table Screen
✍
