230 C HAPTER 13: X.25
Local X.25
Address
This field is the numeric identifier of this particular X.25 endpoint. If the port is
connected to a network (PDN), this number is supplied by the vendor. When two
TXPORT units are directly connected, any value may be entered. TXPORT
suggests using the telephone number of the office where the unit is located. The
selections are up to 15 digits (numeric only), blank.
X.25
Access
List
Line
Module
This field indicates the line module number of the port being displayed. Entering a
different line module number and pressing F10 transfers the program to the same
port on the new line module.
Port The port field indicates the number of the port being displayed. A different port
may be selected by entering its number here and pressing F10.
Copy
Stations
This function allows retrieving the addresses for a previously defined port and
copying them into the current configuration.
Configuration
Enter the configuration number where the stations to be copied reside.
Module
This parameter represents the line module number in the source unit.
Port
Enter the port number where the source stations reside.
TXPORT INTELLINET Configuration Program
Configuration 888 X.25 chapter
X.25 Access List Parameters
Line Module 1 Port 1 X.25 Transport
Access Address Primary Access Name Alternate Access Name
[ ] [ ] [ ]
[ ] [ ] [ ]
[ ] [ ] [ ]
[ ] [ ] [ ]
[ ] [ ] [ ]
[ ] [ ] [ ]
[ ] [ ] [ ]
[ ] [ ] [ ]
[ ] [ ] [ ]
[ ] [ ] [ ]
ESC=Main F1=Help F5=Clear F7=Update F10=Leave
Figure 13-5 X.25 Access List Parameters Screen
